- Page 1 15" PANEL MOUNT INDUSTRIAL MONITOR REVISION H USER MANUAL Model No. HIS-ML15- _ _ _ H...
-
Page 2: Table Of Contents
Table of Contents Safety and Regulatory Information ��������������������������������������������������������������������������������3 FCC Notice ����������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations �������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ����������������������������������������������� 4 Mechanical Drawings ������������������������������������������������������������������������������������������������������5 Front and Side Views �������������������������������������������������������������������������������������������������������������� 5 Bottom View ���������������������������������������������������������������������������������������������������������������������������� 5 Rear View ������������������������������������������������������������������������������������������������������������������������������� 6 Installation Instructions ��������������������������������������������������������������������������������������������������7 Step 1: Prepare for Installation ����������������������������������������������������������������������������������������������... -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Safety and Regulatory Information WARNING! To prevent fire or shock hazard, do not expose live components to rain or moisture. Dangerously high voltages are present inside the unit� Do not disassemble the unit. Refer servicing to qualified personnel only. Operator could be exposed to dangerously high voltage if AC power is not connected properly�... -
Page 4: Hazardous Locations
Users should contact their supplier and check the terms and conditions of the purchase contract� When purchased directly from Hope Industrial Systems, you may contact technical support for disposal arrangements. -
Page 5: Mechanical Drawings
Mechanical Drawings Mechanical Drawings Front and Side Views 437.8 mm (17.24") 291.1 mm 353.6 mm 231.6 mm (13.92") (11.46") (9.12") 307.6 mm (12.11") 7.1 mm (0.28") Bottom View 348.0 mm (13.70") 53.3 mm (2.10") (Design to maximum depth of 63.5 mm to ensure future compatibility with later revisions 7.1 mm and replacement units.) -
Page 6: Rear View
Mechanical Drawings Rear View MENU 100 mm VESA Mounting Pattern (M4 screws provided, 16 mm maximum depth of screw) ML15H User Manual, 99141B, September 2021... -
Page 7: Installation Instructions
Installation Instructions Installation Instructions Step 1: Prepare for Installation IMPORTANT! Perform the following steps BEFORE installation of the monitor into the panel. 1� Ensure that sufficient power is available. 2� Ensure that sufficient space is available to allow for proper air flow into and out of the unit�... -
Page 8: Step 2: Bench-Test Configuration
Installation Instructions Step 2: Bench-test Configuration Make sure everything works before installing into the production environment. TIP! If using a KVM extender, please refer to the installation instructions included with the KVM extender module. It is particularly important to bench-test the full configuration prior to final installation. - Page 9 If the video source has a 5 wire analog RGB video output, this can be converted for use with the VGA video port using a simple adapter� Certified adapters are available from Hope Industrial Systems. Contact our sales team for more information�...
-
Page 10: Install Touch Screen Driver
Serial ports are present on all touch screen monitors, but only one should be used to connect the touch screen interface to the monitor� Contact Hope Industrial Systems if you require a CD-ROM with documentation and drivers for touch screens. For a full list of downloadable drivers, please check the following Internet address: https://www�HopeIndustrial�com/support/drivers/... - Page 11 Installation Instructions the bracket, route one end of the USB cable through the retention bracket and connect it to the USB input port on the monitor. Connect the other end to the USB port on the host computer� NOTE: If this step is not performed, the product will not comply with Class I, II, III, Division 2 Hazardous Location requirements.
-
Page 12: Step 3: Install Into Panel
Once you have completed the full bench-test configuration and confirmed that all components are working properly, you are ready to install the monitor into its panel cutout. WARNING! Hope Industrial Systems will not assume liability for damage to internal electronics due to improper installation� Contact Hope Industrial Systems if you need additional assistance�... - Page 13 6� Refer to the enclosure mounting diagram below. 7� Insert the unit into the front of the panel and re-attach the collar� NOTE: Contact Hope Industrial Systems if for any reason your application does not allow for installation of the collar�...
-
Page 14: Video Settings
Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1024 x 768) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image. -
Page 15: Control Panel Buttons
Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. MENU CONTROL PANEL BUTTONS 1� To open the OSD menu, press the Menu button. NOTE: All OSD menus and adjustments screens disappear automatically after 60 seconds. - Page 16 Video Settings Button Control Functions Menu • Opens the OSD menu� • Exits the submenu� • Exits the OSD menu� Select / When the OSD menu IS NOT displayed: Navigate Down • Shortcut to Auto setup function� When the OSD menu IS displayed: •...
-
Page 17: On-Screen Display (Osd) Menus
Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press the Menu button once. Main Menu Description Picture Includes the Contrast, Brightness, Sharpness, and Color functions� VGA Settings Includes the Timing, Auto setup, H total, V position, H position, and Phase functions�... - Page 18 Video Settings Color Menu The Color submenu in the Picture menu includes the Auto color, Theme mode, Gamma, Color balance, and User color functions. Color Menu Description Auto color Auto color is an auto adjust routine to compensate, for example, analog signal level drops on long VGA cables.
-
Page 19: Vga Settings Menu
Video Settings Color Menu Description Color balance Provides several color adjustment modes, including preset color temperatures and a User color mode that allows individual adjustment of Red, Green, and Blue. The factory default setting for this product is Normal� • User color allows individual adjustment of Red, Green, and Blue�... -
Page 20: Setup Menu
Video Settings VGA Settings Menu Description H total Allows the user to fine tune the horizontal timing by increasing or decreasing the total horizontal pixels. H total affects how the image is stretched horizontally. V position (Vertical Moves the screen image up and down. Position) H position (Horizontal Moves the screen image left and right. - Page 21 Video Settings Setup Menu Description The OSD submenu provides several adjustments for the OSD menu settings. • Time out sets the length of time (in seconds) the OSD screen is displayed. For example, with a "60" setting, if a control is not pushed within 60 seconds, the display screen disappears�...
- Page 22 Video Settings Setup Menu Description Source scan Allows the user to turn source scan "On" or "Off." When Source scan is enabled and there is no active video signal present, the display will cycle through video connections until a video source is detected�...
-
Page 23: Cleaning Instructions
Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. All displays may be cleaned using any standard glass cleaner as long as there is no abrasive or oily content. -
Page 24: Troubleshooting
If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem� Please refer to the troubleshooting section of the KVM extender manual or contact Hope Industrial Systems for additional assistance. Symptom Causes... - Page 25 Troubleshooting Symptom Causes Solutions "Scanning Ports / No Video cable is not plugged Check the video cable connection at Signal" message box in correctly� the monitor, PC, and/or KVM extender. and no image on the PC is not powered on� Ensure PC is powered on�...
-
Page 26: Touch Screen Troubleshooting
Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following Internet address: https://www�HopeIndustrial�com/support/drivers/ Symptom Causes Solutions No response when Touch screen driver has Download and install the latest driver touching the touch not been installed�... -
Page 27: Specifications
Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 15" diagonal Image Size (W x H) 304 mm x 228 mm (12�0" x 9�0") Native Resolution XGA (1024 x 768, 4:3 aspect ratio) Minimum Resolution 640 x 400 Pixel Pitch 0�297 mm x 0�297 mm Number of Colors... -
Page 28: Video
Specifications Video Input Connectors • HD-15, DVI-I • Compatible inputs using optional adapter (contact Hope Industrial Systems for details): • HDMI (via HDMI to DVI adapter) • DisplayPort (via DisplayPort to DVI adapter) • BNC (via HD-15 to 5-wire BNC adapter) Input Signal Formats •... -
Page 29: Functional
Specifications Functional Control Panel Buttons Menu, SEL (Navigate Down / Auto setup), ◄ (Left / Down / Brightness Adjustment), ► (Right / Up / Input Source), Power On-Screen Display (OSD) Contrast, Brightness, Sharpness, Color, Timing, Auto setup, H Menus total, V position, H position, Phase, Inputs, OSD, Info, Reset to factory defaults, Source scan, Advanced Setup Touch Screen Option 5-wire resistive system;... -
Page 30: Compliances And Certifications
A, B, C, and D; Class II, Division 2 for Groups F and G; Class III; Temp Code T4A (File No. E328481) per UL121201-2017 and CAN/CSA C22�2 No� 213-17 ML15H User Manual, 99141B, September 2021 © 2021 Hope Industrial Systems, Inc. -
Page 31: Warranty Statement
The warranty on all industrial display and keyboard products, KVM2 extender series, and ENCL-TC/ENCL-PC enclosure series remains in force for a five year period beginning on the date we invoice you� If Hope Industrial Systems repairs or replaces a product under warranty, its warranty term is not extended�... - Page 32 France Germany Phone: +44 (0) 20 7193 2618 Phone: +44 (0) 20 7193 2618 HopeIndustrial.fr HopeIndustrial.de Italy Spain Phone: +39 80 0740414 Phone: +34 91 1438229 HopeIndustrial.it HopeIndustrial.es ML15H User Manual, 99141B, September 2021 © 2021 Hope Industrial Systems, Inc.
